Equivalent Specifications:

CW721R

CuZn39AlFeMn

Nominal Composition:

Copper	56.50 to 58.50%
Tin	0.20 to 0.80%
Manganese	0.50 to 2.00%
Aluminum	1.5% Max
Lead	0.50 to 1.50%
Iron	0.30 to 1.00% Max
Other Impurities	0.50% Max
Zinc	Remainder

Key Features:

» Machinability rating of 100%.
» Excellent capacity for hot forming.
» Good Corrosion resistance.
» Excellent suitability for Brazing and Soldering.

Tensile Strength	430 Mpa Min.
Proof Stress	230 Min.
Elongation	20 Min.

Application:

Due to the enhanced properties of CZ114 brass it is widely used in High Strength Components, Marine Fittings, Railway carriages, gas valves and stems, hardware, gears, Door lock Parts, Yacht Fittings, Lift Track Sections and Heavy Duty connectors.

---

CZ 115

CZ115 is a type of High Tensile Brass with higher percentage of Aluminum and finds its application where strength and Corrosion resistance are required. This grade has a poor machinability rating but is excellent for hot forgeability. Sometimes it is also referred as Manganese Bronze. The Aluminum and Tin Percentage helps in brighter finish of the material with improved corrosion resistance. The addition of Iron helps in improving the strength level of the material.

Equivalent Specifications:

CW721R

CuZn39AlFeMn

Nominal Composition:

Copper	56.50 to 58.50%
Tin	0.20 to 0.80%
Manganese	0.50 to 2.00%
Aluminum	1.5% Max
Lead	0.50 to 1.50%
Iron	0.30 to 1.00% Max
Other Impurities	0.50% Max
Zinc	Remainder

» Good Corrosion resistance

» Improved Ductility with Good strength.

» Excellent for Hot Forming and Bending

Physical Properties:

Tensile Strength	430 Mpa Min.
Proof Stress	230 Min.
Elongation	20 Min.

Typical Applications:

Due to the enhanced properties of CZ114 brass it is widely used in High Strength Components, Marine Fittings, Railway carriages, gas valves and stems, hardware, gears, Door lock Parts, Yacht Fittings, Lift Track Sections and Heavy Duty connectors.
